Product features - 230V emergency power battery
With the emergency battery, our OML strip light 230V can continue to be operated at reduced brightness for a maximum of 2 hours if the power supply is interrupted.
It has an internal battery charge protection with protection against overcharging and overdischarging. The emergency power battery is supplied with a 1.5 m connection cable with a Schuko plug. The battery status can be displayed by pressing the illuminated pushbutton when the emergency function is switched on:
Number of red light flashes (blinking):
- 1× = 0 %-20 % remaining power
- 2× = 20 %-40 % remaining power
- 3× = 40 %-60 % remaining power
- 4× = 60 %-80 % remaining power
- 5× = 80 %-100 % remaining power
High-Capacity & Safety: Equipped with 133.2Wh capacity, retaining 80% energy after 1,000 cycles.
Features Grade A automotive battery cells for precise voltage and temperature control, preventing internal damages from high temperatures.
Fast Charging & Recharging Options: Enjoy swift charging with dual capabilities.
Portable & Compact: Small and lightweight with a 40% energy boost from an automotive-grade battery, while shrinking size by 41%. Airplane-friendly ideal for emergencies.
| Power: | 50W |
| Emergency operation Battery: | 120min. |
| Battery status: | Indicated by indicator light |
| Connected power: | max. 1,500W |
| Input voltage: | 100-277 VAC |
| Output voltage: | 175 VDC |
| Battery: | 22.2 V 6,000 mAh Li-ion battery |
| Charging time: | >8 h |
| Emergency release time: | <1 s |
| Protection category: | IP65 |
| Impact resistance: | IK08 |
| Operating temperature: | -10°C to +45°C |
| Connection cable: | 1.5 m (3×1.5 mm² H07 RN-F with Schuko plug) |
| Emergency operation Brightness: | |
| 10 m | 30% 450 lm / m |
| 25 m | 20 % 300 lm / m |
| 50 m | 10 % 150 lm / m |
